Quick Change Hex Shank High Speed Steel Short Length Drill Bit for Metal Steel

Material : High Speed Steel
Point : 135° Split Point
Shank Type : Hex Shank
Process : Fully Ground
Finish Type : Plain

Brand:
SUBORUI

Quantity:
Availability:





Inquire Add to Basket

Product Description

● Manufactured from M2 premium grade high speed steel. For use in a wide range of materials in the iron and steel families

such aluminum, iron, stainless steel and other hard metal drilling.
● The 135 degree split point tip and twist design helps with cutting speed while providing easy self centering without walking.

● 1/4" Hex Shank can be used in quick change impact drivers.

● For use in a wide range of materials in the iron and steel families such aluminum, iron, stainless steel and other hard metal drilling

Metric size

Size (mm)	Total Length (mm)	Overall Length (mm)
1.5	63.5	16
2	65.1	17
2.5	66.7	19
3	69.9	22
3.5	71.4	24
4	73	25
4.5	76.2	27
5	77.8	27
5.5	79.4	27
6	81	27
6.5	82.6	27
7	85.7	27.3
7.5	87.3	28.9
8	88.9	30.5
8.5	92.1	33.6
9	93.7	35.2
9.5	95.3	36.8
10	96.8	38.4
10.5	98.4	40
11	101.6	43.7
11.5	103.2	44.7
12	104.8	46.3
12.5	106.4	47.9
13	108	49.3
